GSM Access Control Unit

CellOpener-365

GSM Access Control

  • 12-18 VAC/DC
  • Up to 2000 Programable Users
  • Cell Phone SMS Activation
  • Weekly & 365 Day timer
  • Remote Programming From Anywhere in the World
Request Info

CELLOpener-365 Overview

This GSM access control system allows up to 2000 registered users to operate any garage door/gate using their phone with no cost for the call to the user. This simple-to-use access control system uses a GSM SIM card that must be activated upon installation. Simply dial the associated phone number for the SIM Card from any phone or mobile phone and the gate will open without any cost of a call to you. The CellOpener-365 also allows for an input contact to be used to trigger an SMS text message to a property manager letting them know that someone is at the gate or door.

In addition, the unit offers Weekly Timer and 365 Day Timer capability to offer maximum security and allow a property manager to prevent a gate or overhead door from opening on certain days and times such as national holidays or special events. The current date and time are automatically set via the GSM network so there is never a reason to ever make adjustments for daylight savings time.

All programming of the CellOpener-365 occurs using simple SMS text commands. This feature allows programming to be done remotely from anywhere in the world making life easy for maintenance, security, and HR staff that need to enable or disable an individual person’s access to a site.

CellOpener-365 Features

  • Up to 2000 Programable Users
  • Weekly & 365 Day timer
  • AutoAdjust for Day Light Savings Time
  • Remote Programming From Anywhere in the World
  • GSM SIM Card Included
  • Cell Phone SMS Activation Required

CellOpener-365 Specs

Power 12V – 18V AC or DC
Standby Current–LEDs enabled 0.2A @ 12 VDC / 0.3A @ 24 VDC
Standby Current-LEDs disabled 0.1A @12 VDC / 0.15A @ 24 VDC
Max Authorized Users 1600 Normal Users and 400 Special Users
Relay Contact Rating 5A @ 24V
Operating Temperature Min -40°C / Max 65°C
Antenna Cable Length 1 m (39.4 inches)
Lead Cable Length 0.5 m (19.7 inches)
