P-710-HA PROXIMITY READER

The TRES-P-710 Proximity Reader delivers robust and durable performance, with excellent compatibility across a range of electronic access control systems. This versatile device, operating on 125-kHz Proximity RFID technology, can be mounted on various surfaces and supports multiple proximity card and tag technologies. With a reliable read range up to 15 inches and a maintenance-free operation, this reader epitomizes efficiency and adaptability. With dimensions of 6″W x 8.5″H x 1″D, it seamlessly integrates into diverse applications.

Request information

Vehicle Detectors

Safety

Access Controls

The TRES-P-710 Proximity Reader delivers robust and durable performance, with excellent compatibility across a range of electronic access control systems. This versatile device, operating on 125-kHz Proximity RFID technology, can be mounted on various surfaces and supports multiple proximity card and tag technologies. With a reliable read range up to 15 inches and a maintenance-free operation, this reader epitomizes efficiency and adaptability. With dimensions of 6″W x 8.5″H x 1″D, it seamlessly integrates into diverse applications.

Features of Our TRES-P-710 Proximity Reader

  • Employs the reliable and trusted 125-kHz Proximity RFID technology
  • Robust yet compact design: 6″W x 8.5″H x 1″D (216 mm x 152 mm x 25.4 mm)
  • Compatible with a broad array of electronic access control systems
  • Supports a variety of proximity card and tag technologies including Pyramid Series Proximity Cards and certain HID and AWID 125-kHz Proximity protocols
  • Provides a consistent read range up to 15 inches (378 mm)
The TRES-P-710 Proximity Reader distinguishes itself with its:

  • Flexible mounting options – capable of installation on diverse surfaces including metal door and window frames
  • Operates at a voltage of +5 – 16 VDC with a typical current draw of 215 mA, and a peak at 600 mA at 12 VDC
  • Compliant with multiple certifications including FCC, ICC, CE, C-Tick, UL Standard 2941, and IP67, affirming its quality, safety, and resistance to environmental conditions

Its outstanding compatibility and dependability make the TRES-P-710 Proximity Reader a comprehensive and robust solution for managing access control systems effectively and securely, thus enhancing your overall security operations.

RFID Type Proximity RFID
Operating Frequency 125 kHz
Dimensions 6″W x 8.5″H x 1″D (216 mm x 152 mm x 25.4 mm)
Read Range Up to 15 inches (378 mm)
Mounting Options Mullions, including metal door and window frames, and other surfaces
Weight 20 oz (567g)
Applications Electronic Access Control Systems
Power Supply +5 -16 VDC, 215 mA typical, 600 mA peak@ 12 VDC
Operating Temperature -40° F to 149° F (-40° C to +65° C)
Certifications FCC, ICC, CE, C-Tick, UL Standard 2941, IP67
Technologies Supported TRES-P-710: Pyramid Series Proximity Cards and Tags, TRES-P-710-H: Pyramid+ certain HID 125-kHz Proximity protocols, TRES-P-710-A: Pyramid + certain AWID 125-kHz Proximity protocols, TRES-P-710-H-A: Pyramid+ certain HID Proximity protocols+ certain AWID 125-kHz Proximity protocols

Spec Sheet
