P-620-HA – MULLION-MOUNT READER AND KEYPAD

P-620-HA Mullion-Mount Reader & Keypad is a flagship offering from Farpointe Data’s renowned EMX Pyramid Series Proximity®. Setting the pinnacle in electronic security for 125-kHz proximity readers, cards, and tags, this device is built on the foundation of tried-and-true contactless digital radio frequency identification (RFID) technology. It’s designed to seamlessly interface with a wide array of electronic access control systems, thanks to its compliance with the Wiegand communication protocol. Users will appreciate its value-add features, notably MAXSecure™ and fleaPower™. A standout feature is its adaptability – it can be tailored to support multiple proximity card and tag technologies. Plus, with Pyramid cards and tags being passive devices, maintenance is a breeze; there’s no need for batteries. All in all, the EMX-P-620-HA promises to be an indispensable tool for any modern security system, combining efficiency, adaptability, and reliability.

PART NUMBERS:

  • TRES-100-P-620-HA

P-620-HA – MULLION-MOUNT READER AND KEYPAD Overview

P-620-HA MULLION-MOUNT READER & KEYPAD

EMX Pyramid Series Proximity® establishes the gold standard in electronic security for 125-kHz proximity readers, cards, and tags.

Frequency: 125 kHz

Read Range: Up to 5 inches (126 mm)

Dimensions: 1.78″W x 6.1″H x 0.91″D



Features of Our TRES-P-620-HA Mullion-Mount Reader & Keypad

  • Advanced 125-kHz Proximity RFID technology
  • Dimensions: 1.78″W x 6.1″H x 0.91″D (45 mm x 155 mm x 23 mm)
  • Interfaces with diverse electronic access control systems via Wiegand
  • Key features include MAXSecure™M and fleaPower™M
  • Supports multiple proximity card and tag technologies
  • Impressive read range up to 5 inches (126 mm)
The TRES-P-620-HA Mullion-Mount Reader & Keypad stands out with:

  • Adaptable mounting on mullions, metal door and window frames, and other surfaces
  • Battery-free passive design, minimizing maintenance
  • Endorsed by certifications: FCC, ICC, CE, C-Tick, UL Standard 2941
  • IP67 protection rating ensures durability
  • Optimal operating voltage of +5 – 16 VDC
  • Support for both Pyramid Series and specific HID and AWID 125-kHz Proximity protocols

With its state-of-the-art specifications and reliability, the TRES-P-620-HA Mullion-Mount Reader & Keypad is a premier choice for advanced access control and security solutions.



P-620-HA – MULLION-MOUNT READER AND KEYPAD Specs

Specification Details
Product Model TRES-P-620-HA
Technology Proximity
Frequency 125 kHZ
Mounting Mullions, metal door and window frames, and other surfaces
Dimensions 1.78″W x 6.1″H x 0.91″D (45 mm x 155 mm x 23 mm)
Weight 4 oz (113g)
Certifications FCC, ICC, CE, C-Tick, UL Standard 2941
IP Code IP67
Voltage +5 – 16 VDC
Current Draw 70 mA typical, 110 mA peak @ 12 VDC
Read Range Up to 5 inches (126 mm)
Technologies Supported TRES-P-620: Pyramid Series Proximity Cards and Tags
TRES-P-620-H: Pyramid + certain HID 125-kHz Proximity protocols
TRES-P-620-A: Pyramid + certain AWID 125-kHz Proximity protocols
TRES-P-620-H-A: Pyramid + certain HID and AWID 125-kHz Proximity protocols

Spec Sheet
